Lightweight
RELiON lithium batteries provide more power than lead-acid batteries and are typically half the weight. Boosting both performance and agility on the water.
Temperature Tolerant
Lithium batteries can handle a wide variety of conditions and are even 2.5x more efficient at low temperatures than lead-acid while being able to safely operate up to 149°F (65°C).
Fast Charging
RELiON lithium batteries charge much faster than traditional lead-acid batteries, and they’re packed with more usable energy and up to 10 times longer life so you’re always ready to go!
Long Life
RELiON lithium batteries provide up to 10 times longer life than lead-acid batteries, and they still provide 80% of the rated capacity after 3,500 cycles.
Maintenance Free
RELiON lithium batteries are maintenance-free – no watering, no corrosion. Low self-discharge means the batteries don’t lose capacity when they’re idle, assuring that you have the energy you need, every time you need it.
Constant Power
Full power available throughout discharge. Voltage does not drop like lead-acid.
Partial State of Charge Tolerant
Partial state of charge, known as PSOC, which is a killer of lead-acid batteries, does not affect performance or battery life of a lithium battery. Sometimes batteries don’t get fully charged, or they regularly operate in a partial state of charge. Either way, you can count on RELiON lithium batteries living a long and productive life.
More Usable Capacity
Lead-acid batteries are typically sized up to two times your energy needs to account for extended periods without sun and less usable energy with higher rates of discharge. Plus, you are typically cautioned to limit your use to 50% of the rated capacity, as using more can significantly reduce performance. Lithium batteries provide 100% of their rated capacity, regardless of the rate of discharge. And, you can use it all and still get substantially longer cycle life.
Electrical Specifications |
|
---|---|
Nominal Voltage | 12.8 V |
Nominal Capacity | 300 Ah |
Capacity @ 25 A | 720 min |
Resistance | ≤30 mΩ @ 50% SOC |
Efficiency | 99% |
Self Discharge | <3% per Month |
Maximum Batteries Connected in Series | 6 |
Mechanical Specifications |
|
---|---|
Dimensions (L x W x H) | 20.6 x 10.5 x 8.7” (522 x 267 x 220 mm) |
Weight | 75.8 lbs (34.36 kg) |
Terminal Type | M8 x 1.25 x 2mm |
Terminal Torque | 80 - 100 in-lbs (9 - 11 N-m) |
Case Material | ABS & Polycarbonate blend (UL94-V0 flame rating) |
Enclosure Protection (Waterproof Rating) | IP67 |
Cell Type - Chemistry | Cylindrical - LiFePO4 |
Discharge Specifications |
|
---|---|
Maximum Continuous Discharge Current | 100 A |
Peak Discharge Current | 200 A (7.5 s ±2.5 s) |
Discharge Over-Current Protection | 280 A ±50 A (9 ±4 ms) |
Recommended Low Voltage Disconnect | 11.0 V |
Discharge Under-Voltage Protection | 8.0 V (2.0 ±0.08 vpc) (140 ±60 ms) |
Reconnect Voltage | 9.2 V (2.3 ±0.1 vpc) |
Short Circuit Protection Response Time | 200-600 µs |
Charge Specifications |
|
---|---|
Recommended Charge Current | 15 A - 50 A |
Maximum Continuous Charge Current | 100 A |
Maximum Charge Current 14 to 32 ºF (-10 to 0 ºC) | ≤0.1 C (10 A) |
Maximum Charge Current -4 to 14 ºF (-20 to -10 ºC) | ≤0.05 C (5 A) |
Recommended Charge Voltage | 14.2 V - 14.6 V |
BMS Charge Voltage Cut-Off | 15.6 V (3.9 ±0.025 vpc) (1.1 ±0.4 s) |
Reconnect Voltage | 15.2 V (3.8 ±0.05 vpc) |
Balancing Voltage | 14.4 V (3.6 ±0.025 vpc) |
Temperature Specifications |
|
---|---|
Discharge Temperature | -4 to 140 ºF (-20 to 60 ºC) |
Charge Temperature* | -4 to 113 ºF (-20 to 45 ºC) |
Recommended Storage Temperature | 23 to 95 ºF (-5 to 35 ºC) |
BMS High Temperature Cut-Off | 176 ºF (80 ºC) |
Reconnect Temperature | 122 ºF (50 ºC) |
Compliance Specifications |
|
---|---|
Certifications | UN38.3, UKCA & CE (battery) |
UL1642 (cells) (File# MH64523) | |
IEC62133 (cells) | |
Shipping Classification | UN 3480, CLASS 9 |
Performance Characteristics
Pete S.
Jun 15th, 2021
Arrived as promised. Very impressive packaging. We are now installing them in my sailboat. They replace four 13-year-old AGM batteries for all "House Loads," everything, including winches, except engine start.
Scott C.
Oct 29th, 2020
Super awesome product support! Super fast and accurate shipping! Batteries work amazing! I really like the long lasting power that I have now. I boon-dock mainly and having battery power is crucial. Thanks for a superior product and service!
Other Documentation
Learn which battery is right for a Class A, Class B, or Class C RV. We also cover typical 5th wheel campers, toy haulers, travel trailers, and pop-up trailers.
Learn how sailing with RELiON lithium batteries helped Stephen and Dawn sail around the world.
