The InSight 48V-LT was built specifically to meet the power and energy requirements in utility vehicles, solar, and AGV applications. The 30Ah outputs 100A continuous and offers higher peak discharge, plus, with the LT technology, it can safely charge at temperatures down to -20°C (-4°F) which makes it ideal in cold weather applications.
$1,249.95
ENGINEERED IN THE USA
US-BASED SUPPORT
10 YEAR WARRANTY
Cold Weather Ready
Featuring our Low Temperature Series (LT) technology, the InSight 12V battery can safely charge at temperatures down to -20°C (-4°F).
Easy Installation
InSight batteries come in BCI group size GC2/GC8 allowing for easy installation without modifying trays or battery compartments.
Scalable System
InSight batteries offer freedom and flexibility by utilizing parallel connections, so you can scale your system to provide increased power and energy (up to 300Ah) as needed.
Intelligent Cooling
InSight Series® uses a carefully engineered cooling management system to quickly remove heat from inside the battery during conditions of high discharge and recharge currents. This prevents overheating of critical components and extends the life of the battery.
SuperSmart BMS
The robust Battery Management System features a combined total of 48 charge and discharge MOFSETs that control current flow in and out of the battery, along with multilayer protective devices that prevent over/under voltage, current and temperature conditions. The multilayer protection allows InSight batteries to pass stringent UL safety standards.
Robust Communication
CANbus connections allow batteries to communicate real-time operating statistics like the voltage, current, state of charge and state of health, making InSight batteries more user friendly. Plus, all batteries feature a sleep and pulse recovery operation mode to conserve power.
FUNCTIONAL SPECIFICATIONS |
|
---|---|
Nominal Voltage | 51.2V |
Cell Chemistry | LiFePO4 |
Cell Type | Prismatic |
Ampere-hour Capacity | 30Ah |
Watthour Capacity | 1536 Wh |
Impedance (50% SOC, 1kHz) | <150mΩ |
Cycles @ 80% DOD | >3500 |
Parallel Capable | Yes (up to 10) |
Series Capable | No |
MECHANICAL SPECIFICATIONS |
|
---|---|
BCI Size | GC2 / GC8 |
Dimensions (LxWxH) | 260x180x276mm (10.2x7.1x10.9in) |
Weight | 15.6 kg (34.4 lbs) |
Case Material | ABS |
Stud / Insert Terminal | M8 X 1.25 - 20 |
Ingress Protection Marking | IP67 |
Case Flame Rating | UL94 V-0 |
DISCHARGE SPECIFICATIONS |
|
---|---|
Recommended Continuous Discharge Current | 45A (1.5C) |
Maximum Continuous Discharge Current | 100A |
Peak Discharge Current | 100A<lbatt<120A, 10s 150A<lbatt<180A, 5s 180A<lbatt<250A, 1s Ibatt>250A, 0.5s |
Short Circuit Protection | 350A |
Short-Circuit Reset | Automatic |
Discharge Cut Off Pulse Recovery Operation | Automatically above 2.9V/cell (46.4V) |
Low Voltage Protection | 2.8V/cell (44.8V)~6 months @ 25°C (60°F) |
Permanent Off Voltage | 1.8V/cell (28.8V) |
CHARGE SPECIFICATIONS |
|
---|---|
Recommended Charge Current | 15A (0.5C) |
Continuous Charge Current | ≤ 30A (1C) |
Disconnect Charge Current | 30A≤lbatt<50A, 5s |
Peak Charge Voltage | 57V |
Float Voltage | 54V |
Over-Voltage Protection | 3.65V/cell 4s (58.4V) |
Over-Voltage Reset | Automatically at 3.6V/cell (57.6V) |
Heating Rate | 20°C/hr (35°F/hr) |
ENVIRONMENTAL SPECIFICATIONS |
|
---|---|
Charge Under Temperature | -20°C (-4°F) for 2s. Self-heating function will be activated below 0°C (32ºF). Self-reset function. |
Charge Over Temperature | 55°C (131°F) for 2s. Self-reset function. |
Discharge Under Temperature | -20°C (-4°F) for 2s. Self-reset function. |
Discharge Over Temperature | 55°C (131°F) for 2s. Self-reset function. |
Operating Humidity Range | 10% to 95% RH non-condensing |
Optimal Storage Temperature | 10°C to 35°C (50°F to 95°F) |
Optimal Storage Humidity | 15% to 90% RH |
CERTIFICATIONS |
|
---|---|
UL2580 (Cell) | |
UL2271 (Battery Pack) | |
CE (Battery Pack) | |
IEC 62133-2 :2017 (Lithium Batteries) |
SHIPPING CLASSIFICATION |
|
---|---|
UN3480, Class 9 |
TYPICAL LITHIUM IRON PHOSPHATE CHARACTERISTICS
