ELiTE Series 48V

48V 32Ah
Deep Cycle Lithium Battery
GC2

ELiTE Series 48V

48V 32Ah
Deep Cycle Lithium Battery
GC2

Designed for golf carts, utility vehicles, AGVs and similar applications, the RELiON ELiTE™ 48V offers outstanding performance, with a high discharge rate for no-lag power delivery, a sophisticated, safety-enhancing BMS, and rapid 2C charging. At the same time, drop-in installation and LED charge state indicators ensure ultimate ease of use.




COMING SOON

Us Flag Small

ENGINEERED IN THE USA

United States Of America White 230216 103954

US-BASED SUPPORT

Warranty White 230216 103954

Extensive Warranty

Features

Features:

Engineered for Performance

With a high discharge rate, the RELiON ELiTE benefits from no-lag, fast-off-the-line performance. This translates to rapid acceleration and smooth and consistent power delivery. Fast 2C charging ensures users spend less time tied to shore power.

Engineered for Ease

The RELiON ELiTE benefits from drop-in installation, so users are up and running immediately. GC2 casing means no modifications to the battery compartment, reducing integration costs and making the ELiTE the battery of choice for users who prefer quick, simple, and hassle-free setup. Once installed, LED indicators provide clear insight into the charge state.

Engineered for Safety

Our in-house experts leveraged more than 10 years of lithium-exclusive experience to develop the ELiTE’s advanced, safety-enhancing BMS. It provides advanced multi-layer voltage, current, and temperature protections to maximize performance, minimize maintenance, and deliver power safely.

Engineered for Dependability

Ground-up design and development mean the ELiTE delivers reliable and consistent performance, taking RELiON battery technology to the next level. An extensive warranty protects battery investment and easy access to technical support from our lithium experts means help is always at hand.

Engineered for Integration

With CANopen, CZone® and NMEA 2000® communication, the ELiTE guarantees seamless application integration, out-of-the-box interoperability, and enhanced communication reliability.

Specifications

DOWNLOAD PDF

ELECTRICAL SPECIFICATIONS

Nominal Voltage 51.2V
Cell Chemistry Lithium Iron Phosphate (LFP)
Capacity 32 Ah
Nominal Energy 1638 Wh
Cycle Life @ 0.5C & 80%DoD 3500
Output Protection Internal Electronic Switch
Battery Management Systems Embedded BMS
Communication Protocol CanOpen/CZone/N2Kcompatible

MECHANICAL SPECIFICATIONS

Physical Dimensions 260 x 180 x 277 mm (10.2 x 7.1 x 10.9 in)
Size BCI standard GC2 or GC8
Weight ~15.5 kg (~34.0 lbs)
Ingress Protection Grade IP67
Power Terminals M8x15 mm stainless steel stud (LPT)
Communication Connector M12
Remote Button Connector Available
Parallel Connection Up to 24
Series Connection Not Allowed
Touch Safe Protection Yes, Terminal protected

DISCHARGE SPECIFICATIONS

Discharge Current 15A (0.5) Continuous
90A (3C) Maximum
150A (5C) Peak
Short Circuit Resettable 350A

CHARGE SPECIFICATIONS

Continuous Charge Current 15A (0.5C) Recommended
32A (1C) Maximum
64A (2C) Peak
Charge Voltage 57V

ENVIRONMENT & STORAGE SPECIFICATIONS

Operating Temperature [0 to 55] °C on charge
[-20 to 60] °C on discharge
Operating Humidity [15% to 90%] RH
Altitude Up 1500 mt a.s.l.
Storage Temperature <3 months: [-20 to 45] °C<1 year: [-20 to 25] °C
Storage Humidity [10% to 90%] RH
Shelf Life (Depends on environmental conditions and SOC) Up to 20 months SOC>70%
Up to 6 months with SOC>5%

PROTECTION

Low Voltage, Over Voltage, Max. Discharge Current, Max. Charge Current, Max. Temperature, Min. Temperature

COMPLIANCE SPECIFICATIONS

CE (Battery Pack)
UN38.3

*Data is preliminary. Subject to change
